Horsepower 74 hp

Rated Operating Capacity with Bucket (Articulated) 3335 lbs

Rated Operating Capacity with Forks (Straight) 4860 lbs

Rated Operating Capacity with Forks (Articulated) 4127 lbs

Rated Operating Capacity with Bucket (Straight) 3981 lbs

Operating Weight 11993 lbs

Travel Speed – High 24.3 mph

Travel Speed – Low 5.3 mph

Auxiliary Std Flow 19.9 gpm

Auxiliary High Flow 27.3 gpm

Width (over tires) 70.9 in

Horsepower 74 hp

Turbocharged Engine yes

Tipping Capacity with Bucket (Straight) 7962 lbs

Rated Operating Capacity with Bucket (Articulated) 3335 lbs

Rated Operating Capacity with Forks (Straight) 4860 lbs

Rated Operating Capacity with Forks (Articulated) 4127 lbs

Rated Operating Capacity with Bucket (Straight) 3981 lbs

Tipping Capacity with Bucket (Articulated) 6670 lbs

Tipping Capacity with Forks (Straight) 6076 lbs

Tipping Capacity with Forks (Articulated) 5159 lbs

Bucket Capacities 1.25 – 2.0 yd3

Operating Weight 11993 lbs

Travel Speed – High 24.3 mph

Travel Speed – Low 5.3 mph

Capacities L95

Fuel Tank 20.8 gal

Hydraulic System L95

Auxiliary Std Flow 19.9 gpm

Auxiliary High Flow 27.3 gpm

Inside Turning Radius w/bkt 78.2 in

Outside Turning Radius w/forks 180.8 in

Height to Hinge Pin – Fully Raised 128.9 in

Articulation Angle40 deg

Oscillation Angle8 deg

Outside Turning Radius 150.7 in

Length without Attachment: 192.4 in

Length with Standard Bucket: 219.3 in

Width (with bucket) 74.8 in

Width (over tires) 70.9 in

Height with Operator Cab 99.3 in

Dump Angle @ Maximum Height 45 deg

Ground Clearance 13.3 in

Rollback Angle 49 deg

Wheelbase 82.7 in

Tire Size 405/70/R20

Wheel Tread 54.8 in

Drive Type Four-Speed hydrostatic with Advanced Attachment Control
