Horsepower 74 hp
Rated Operating Capacity (ISO) 2900 lbs
Operating Weight 8615 lbs
Auxiliary Std Flow 23.3 gpm
Auxiliary High Flow 30.3 gpm
Joystick Control Optional
Horsepower Management Included with SJC Option
Horsepower 74 hp
Turbocharged Engine yes
Rated Operating Capacity (ISO) 2900 lbs
Rated Operating Capacity 300 lb. Counterweight 3100 lbs
Rated Operating Capacity 200 lb. Counterweight 3050 lbs
Tipping Load 5800 lbs
Operating Weight 8615 lbs
Travel Speed 6.8 mph
Travel Speed (2-speed option) 11.8 mph
Fuel Tank 31.7 gal
Hydraulic System Pressure (Standard and High Flow) 3500 psi
System Relief @ Quick Couplers 3500 psi
Auxiliary Std Flow 23.3 gpm
Auxiliary High Flow 30.3 gpm
Length 141.9 in
Length without Attachment 113.9 in
Length with Standard Bucket 147.1 in
Width 72 in
Width (with bucket) 74 in
Height 81.8 in
Height with Operator Cab 81.8 in
Height to Bucket Hinge Pin 128.3 in
Reach @ Maximum Height 33.5 in
Turning Radius 87.7 in
Wheelbase 48.3 in
** Listed specs based on machine base model. Actual specs may vary depending on model and options **
