Horsepower 92 hp
Rated Operating Capacity (ISO) 3350 lbs
Operating Weight 9314 lbs
Auxiliary Std Flow 23 gpm
Auxiliary High Flow 36.6 gpm
Joystick Control Optional
Horsepower 92 hp
Rated Operating Capacity (ISO) 3350 lbs
Tipping Load 6700 lbs
Operating Weight 9314 lbs
Travel Speed 7.1 mph
Travel Speed (2-speed option) 12.3 mph
Fuel Tank 23.9 gal
System Relief @ Quick Couplers 3500 psi
Auxiliary Std Flow 23 gpm
Auxiliary High Flow 36.6 gpm
Length 141.6 in
Length without Attachment 114.3 in
Length with Standard Bucket 141.6 in
Width 72.1 in
Width (with bucket) 74 in
Height 81.3 in
Height with Operator Cab 81.3 in
Height to Bucket Hinge Pin 131.4 in
Reach @ Maximum Height 33.6 in
Turning Radius 85.8 in
Wheelbase 48.3 in
** Listed specs based on machine base model. Actual specs may vary depending on model and options **
