Horsepower
Operating Capacity
Operating Weights
Horsepower 74 hp
Rated Operating Capacity (ISO) 2400 lbs
Operating Weight 7154 lbs
Auxiliary Std Flow 17.6 gpm
Auxiliary High Flow 26.9 gpm
Joystick Control Optional
Horsepower Management Included with SJC Option
Rated Operating Capacity (ISO) 2400 lbs
Rated Operating Capacity 200 lb. Counterweight 2550 lbs
Tipping Load 4800 lbs
Operating Weight 7154 lbs
Travel Speed 7.4 mph
Travel Speed (2-speed option) 11 mph
Fuel Tank 28.3 gal
Hydraulic System Pressure (Standard and High Flow) 3500 psi
System Relief @ Quick Couplers 3500 psi
Auxiliary Std Flow 17.6 gpm
Auxiliary High Flow 26.9 gpm
Length without Attachment 107 in
Length with Standard Bucket 135 in
Width 67 in
Width (with bucket) 68 in
Height with Operator Cab 80.5 in
Height to Bucket Hinge Pin 120 in
Reach @ Maximum Height 34.2 in
Turning Radius 80.1 in
Wheelbase 44.6 in
** Listed specs based on machine base model. Actual specs may vary depending on model and options **
